Place of Origin:
Japan
Brand Name:
MIMAKI
Certification:
CE
Model Number:
JV300-160Plus
Document:
"JV300 Plus Series" are new model products standing as successor of "JV300 Series".
Environmental consideration, economic performance, and work efficiency have been added as "Plus" features as well as high function.
| JV300-130 Plus | JV300-160 Plus | ||
|---|---|---|---|
| Printhead | On-demand piezo head (2 staggered printheads) | ||
| Print resolution | 360dpi, 540dpi, 720dpi, 1,080dpi, and 1,440dpi | ||
| Maximum print width | 1,361mm (53.5") | 1,610mm (63.3") | |
| Maximum media width | 1,371mm (53.9") | 1,620mm (63.7") | |
| Ink | Type/Color | Eco-solvent ink ・SS21(C,M,Y,K,Lc,Lm,Lk,Or,W) ・BS3(C,M,Y,K)*Only available in specific countries ・BS4(C,M,Y,K)*Only available in specific countries ・ES3(C,M,Y,K,Lc,Lm,W) Sublimation ink ・Sb54(Bl,M,Y,K,Lbl,Lm) |
|
| Package size *1 |
SS21: 440ml Ink cartridge / 600ml Ink pack / 2L Ink pack (*W is provided in 220ml Ink cartridge only) BS3, BS4: 600ml Ink pack / 2L Ink pack ES3: 440ml Ink cartridge (*W is provided in 220ml Ink cartridge only) Sb54: 440ml Ink cartridge / 2L Ink pack |
||
| Circulation system |
MCT (Mimaki Circulation Technology) *2 | ||
| Media thickness | 1.0mm or less | ||
| Rolled media weight | 45kg (99 lb) or less | ||
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1 CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, EAC |
||
| Interface | USB 2.0 / Ethernet 1000BASE-T | ||
| Power supply | Single-phase (AC 100–120V / AC 220–240V) × 2 50/60Hz ±1Hz | ||
| Power consumption | 1,440W×2 or less (at AC 100V system) 1,920W×2 or less (at AC 200V system) |
||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) |
||
| Dimensions (W×D×H) | 2,525mm×700mm×1,392mm (99"×28"×55") |
2,775mm×700mm×1,392mm (109"×28"×55") |
|
| Weight | 170kg (375 lb) | 200kg (441 lb) | |
