| Specification | Details |
|---|---|
| Printing Method | Piezo ink-jet method |
| Media Width | 13.2 to 64 in. (335 to 1,625 mm) |
| Media Thickness |
Printing: Max. 39.3 mil (1.0 mm) with liner
Cutting: Max. 15.7 mil (0.4 mm) with liner and 8.6 mil (0.22 mm) without liner
|
| Roll Outer Diameter | 9.8 in. (Max. 250 mm) |
| Roll Weight | Max. 99 lb. (45 kg) |
| Core Diameter | 3 in. (76.2 mm) or 2 in. (50.8 mm) |
| Printing/Cutting Width | Max. 62.9 in. (1,600 mm) |
| Ink Type | Eco-Solvent Ink (TR3) 500 ml cartridge (only white 220 ml) |
| Color Configurations |
Eight colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, and Green)
Seven colors (Cyan, Magenta, Yellow, Black, Orange, Green, and White (2 cartridges))
Four colors (Cyan, Magenta, Yellow, and Black)
|
| Printing Resolution | Max. 1,800 dpi |
| Cutting Speed | 0.39 to 11.8 in/s (10 to 300 mm/s) |
| Blade Force | 30 to 500 gf |
| Blade Type | Roland CAMM-1 series blade |
| Blade Offset | 0.0 to 59 mil (0.000 to 1.500 mm) |
| Software Resolution (Cutting) | 0.98 mil/step (0.025 mm/step) |
| Media Heating System |
Print Heater: 86 to 113 °F (30 to 45 °C)
Dryer: 86 to 131 °F (30 to 55 °C)
|
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) |
| Power-Saving Function | Automatic sleep feature |
| Rated Input | 100-120 / 220-240 Va.c. 50 / 60 Hz 8.9 / 4.5 A |
| Power Consumption |
Operation: Approx. 1,180 W
Sleep Mode: Approx. 50 W
|
| Acoustic Noise Level |
Operation: 66 dB (A) or less
Standby: 56 dB (A) or less
|
| Dimensions (W x D x H) | 113.7 in. x 29.5 in. x 55.8 in. (2,886 mm * 748 mm * 1,415 mm) |
| Weight | 433 lb. (196 kg) |
| Operating Environment |
During Operation: Temperature: 68 to 89.6 °F (20 to 32 °C), Humidity: 35 to 80 % RH (no condensation)
Not Operating: Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 % RH (no condensation)
|
| Included Items | Dedicated stand, power cord, media take-up unit, media holders, replacement blade for separating knife, cleaning liquid bottle for maintenance, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc. |
